LTO Low-Voltage Residential Home Energy Storage Battery
Working Temperature:-40°C-60°C
Cycle Life:25,000 Times Cycle
Extreme Safety
3+ Cycles a day
Technical Parameter
Items
PL-LTO-LV 5800
| Rated Capacity（kWh） | 5.76Kwh |
| Cell Configuration | 3P20S |
| Rated voltage（V） | 48V |
| Operating voltage Range（V） | 42V-58V |
| Rated charge and discharge current（A） | 100A |
| Rated charge and discharge power（kW） | 5KW |
| Maximum charge and discharge current（A） | 110A |
| Rated capacity（Ah) | 120A |
| Weight（kg） | 92Kg |
| Size (height*width*thickness)(mm) | [620×650m×225]±3mm |
| Operating temperature range（℃） | -40~60 |
| Maximum operating altitude（m） | 4000 |
| Relative humidity（%） | 0-95% |
LTO Low-Voltage Residential Home Energy Storage Battery
Product Advantage
Working Temperature:-40°C-60°C
Cycle Life:25,000 Times Cycle
Extreme Safety
3+ Cycles a day
